RB441T

Rebar Tying Tool up to 22mm x 22mm with 1.0 mm wire

RB441T “TWINTIER” is a 7th generation of Max REBAR-TIER products, the most advanced cordless Re-bar tying machine. The TwinTier mounts 3 new innovative mechanisms making it the most efficient rebar tying tool on the market.

Applications

Precast Plants
Foundations
Road and Bridge
Floor decking
Floor heating
Building floor

SKU: RB441T Categories: Max, Rebar Tag: Cross-Tying Bars

Description

DOUBLE THE SPEED
The Dual Wire Feeding Mechanism increases productivity.
COST SAVINGS
The Wire Pull Back Mechanism dispenses the precise amount of wire needed to form a tie reducing wire usage.
THE TWINTIER
The TwinTier can tie 4000 ties per battery charge and up to 240 ties per coil of wire (on 13mm x 13mm rebar).
SHORTER TIE HEIGHT
The TwinTier’s Wire Bending Mechanism (Pat. Pending) produces a shorter tie height. Less concrete is needed to fully cover a wire tie.
A LARGE JAW
A large jaw enables the TwinTier to tie up to a 22mm x 22mm rebar.
SLIM ARM FITS
Slim arm fits easily at a 45 degree angle for tight ties.
AN EASY PUSH GEAR
An easy push gear release effortlessly opens gears to quickly feed wire when loading the tool.

Specifications

WEIGHT	2.5 KG
DIMENSIONS	295mm (H) x 120mm (W) x 330mm (L)
MINIMUM TIES PER COIL	145
MAXIMUM TIES PER COIL	265
APPLICABLE WIRE PRODUCT/ GAUGE	TW1061T / 19ga. TW1061T-EG / 19ga, TW1061T-PC / 19ga, TW1061T-S / 19ga
APPLICABLE REBAR SIZE	10mm x 10mm - 22mm x 22mm, up to 13mm x 13mm x 16mm x 16mm
TIES PER CHARGE	4000
TIE SPEED	Approx. 1/2 sec
TIE WRAPS	2
BATTERY CHARGE TIME	40 Minutes full charge
BATTERY	JPL914
CHARGER	JC925A
